Acoustic power emissions (active, printing)
6.3 B(A)
Acoustic power emissions (ready)
2.5 B(A)
Acoustic pressure emissions bystander (active, printing)
50 dB(A)
Acoustic pressure emissions bystander (ready)
16 dB(A)
Automatic paper sensor
Yes
Cable included
Yes, 1 USB Cable to 1020 and 1020w (China and India)
Certifications and compliances
RCM (Australia), TUV and GS Mark (Germany), BSMI (Taiwan), CCC (China), BIS (India), KC (South Korea), SIRIM (Malaysia), Cambodia, Ukraine, EAC, Eastern European approvals, CE Marking, FCC, Energy Star (US/CA), UL, Paraguay, Chile, Argentina, Indonesia, Singapore, Philippines, etc.
Color or black
Black and white
Compatible Network Operating Systems
Windows Server 2008 R2 64-bit, Windows Server 2008 R2 64-bit (SP1), Windows Server 2012 64-bit, Windows Server 2012 R2 64-bit, Windows Server 2016 64-bit; Linux.
Compatible Operating Systems
Windows 11; Windows 10; macOS 10.14 Mojave; macOS 10.15 Catalina; macOS 11 Big Sur; macOS 12 Monterey; Linux
Connectivity, standard
Hi-Speed USB (compatible with USB 2.0 specifications
Control panel
2 lights (Paper, Attention); 3 buttons (Resume, Cancel, Power)
Count of layers in pallet
EMEA/APJ: 7; AMS: 8
Country of origin
Vietnam(AB2, ACJ)
Dimension note (imperial)
Depth varies depend on the Tray positions
Dimensions (W x D x H)
13.7 X 11.2 X 8.46 in
Display area (imperial)
Not Applicable
Downloadable software
From: Smart for Windows 11, 10, Mac, Mobile(Android and iOS); Easy Start for Windows 7; Full-solution software and drivers (with installer); Easy Start; Basic-solution software and drivers; Product Documentation and Support; Print and Scan Doctor; From Mobile OS: See " Mobile Printing"; From In-OS app stores: Smart; Print Service Plugin; for printer administrators: Linux Print Drivers; Web JetAdmin Software (SNMP Proxy Agent);
Driver updates
Latest supported operating systems and Print drivers available
Duplex printing
Manual (driver support provided)
Duty cycle (monthly, A4)
Up to 20,000 pages
Duty cycle (monthly, letter)
Up to 20,000 pages
Duty cycle note
Duty cycle is defined as the maximum number of pages per month of imaged output. This value provides a comparison of product robustness in relation to other LaserJet or Color LaserJet devices, and enables appropriate deployment of printers and MFPs to satisfy the demands of connected individuals or groups.
Ecolabels
CECP; EPEAT® Silver India
Electromagnetic compatibility
CISPR32:2015 & CISPR 35:2016 /EN55032:2015- Class B; EN 61000-3-2:2019; EN 61000-3-3:2013+A1:2019; EN 55035:2017; FCC Title 47 CFR, Part 15 Class B/ICES-003, Issue 6
Energy savings feature technology
Auto-On/Auto-Off Technology; Instant-on Technology
Envelope Feeder
Up to 10 Envelopes
First page out black (A4, ready)
As fast as 8.0 sec
First page out black (A4, sleep)
As fast as 8.4 sec
First page out black (letter, ready)
As fast as 7.9 sec
First page out black (letter, sleep)
As fast as 8.3 sec
First page out footnote
Measured using ISO/IEC 17629. Exact speed varies depending on the system configuration, software application, driver, and document complexity.
Input capacity
Up To 150 sheets
Manufacturer Warranty
One-year limited hardware warranty.
Material Type for item
FERT
Maximum dimensions (W x D x H)
13.37X15.37X8.46 in
Maximum input capacity (sheets)
Up To 150 sheets
Maximum Memory
64 MB SDRAM
Maximum output capacity (sheets)
Up tp 100 sheets
Maximum print area
215.9 x 355.6 mm
Media size, tray 1
A6; A5; A4; Letter; No.10 Env; C5 Env; DL Env; B5(JIS); 105 x 148.5 mm to 215.9 x 355.6 mm; 216 mm x 340 mm;
Media sizes supported
Letter; envelopes (No.10); Legal; Postcard; Double Postcard; Executive; Officio; Custom
Media sizes supported, key
4 x 6 in; Letter; Legal; Envelopes
Media sizes, custom
4 x 6 to 8.5 x 14 In
Media type and capacity, tray 1
Sheets: 150; Envelopes: up to 10
Media types
Plain paper, Heavy paper, Bond paper, Label, Light paper, Envelope
Media weight (tray 1)
60 to 163 g/m²
Media weight (tray 2)
No Tray 2
Media weight (tray 3)
No Tray 3
Media weight, supported
16 to 43 lb
Minimum System Requirements
Microsoft Windows 11, 10, 2 GB available hard disk space, Internet connection, USB port, Microsoft® Internet Explorer or Edge.
Minimum System Requirements for Macintosh
Apple macOS v10.15 Catalina, macOS v11 Big Sur, macOS v12 Monterey; 2 GB HD; Internet required; USB
Mobile printing capability footnote
Mobile device needs to be connected to Wi-Fi Direct signal of a Wi-Fi Direct-supported AiO or printer prior to printing. Wi-Fi Direct is a registered trademark of Wi-Fi Alliance.
Number of users
1-5 Users
Operating humidity range
10 to 80%RH
Operating system (supported note)
Not supporting Windows XP (64-bit), Windows Vista (64-bit) and Windows 8, 8.1. Full solution software available only for Windows 10 and newer; For Windows Server 2008 R2 64-bit, 2012 64-bit, 2012 R2 64-bit, 2016 64-bit only print driver is installed. Windows RT OS for Tablets (32 & 64-bit) uses a simplified print driver built into the RT OS; Linux systems use in-OS software.
Operating temperature range
59 to 90.5°F
Output capacity
Up tp 100 sheets
Package dimensions (W x D x H)
17.01 x 13.03 x 11.46 in
Page yield (set-up/inbox cartridges)
~5,000 black pages
Pallet dimensions
EMEA/APJ: 47.24 x 39.37 x 86.14 in; AMS: 47.24 x 39.37 x 97.60 in
Pallet weight
EMEA/APJ: 983.5lb; AMS: 1117.5lb
Paper handling input, standard
Up tp 150 sheets
Paper handling output, standard
Up tp 100 sheets
Paper trays, maximum
1 Input Tray
Power
Rated Voltage:110-127V; Rated Current:5.2A; Frequency:50/60Hz; Rated Voltage:220-240V Rated Current:2.9A; Frequency:50/60Hz
Power consumption
Active printing: 354w, Ready: 1.59w, Sleep: 0.46w, Manual Off: 0.05w, Auto Off/Manual On: 0.05w, Auto-Off/Wake on LAN: 0.4w
Power consumption Note
Power requirements are based on the country/region where the printer is sold. Do not convert operating voltages. This will damage the printer and void the product warranty. Power consumption values typically based on measurement of 115V device.
Power supply type
Internal (built-in) Power Supply
Print Cartridges/Bottle, Number
1 (black)
Print languages
PCLmS; URF; PWG
Print quality black (best)
Up to 600 x 600 dpi
Print quality black (normal)
Up to 600 x 400 dpi
Print resolution black (fine lines)
Up to 600 x 600 dpi
Print Resolution Technologies
600 x 400 dpi; 600 x 600 dpi
Print speed
Print speed up to 22ppm (black, A4)
Print speed black (ISO, A4)
Up to 22 ppm
Print speed black (ISO, letter)
Up to 23 ppm
Print speed black (Landscape, A5)
Up to 23 ppm
Print speed black (Portrait, A5)
Up to 4 ppm
Print speed footnote
Measured using ISO/IEC 24734, excludes first set of test documents. Exact speed varies depending on the system configuration, software application, driver, and document complexity.
Print speed footnote (A5)
Measured using ISO/IEC 24734 Feature Performance Test, excludes first set of test documents. Exact speed varies depending on the system configuration, software application, driver, and document complexity.
Print speed footnote number (A5)
[6]
Printer Management
Printer Assistant (UDC); Device Toolbox; Utility (Mac)
Printer smart software features
Auto-On/Auto-Off
Printer smart software features footnote
Auto-On/Auto-Off Technology capabilities subject to printer and settings; may require a firmware upgrade.
Product long name specifications
LaserJet Tank 1020 Printer, Black and white Printer for Business, Print, Compact Size; Energy Efficient
Product short name specifications
LaserJet Tank 1020 Black and white Printer
Quantity per pallet
EMEA/APJ: 56; AMS: 64
Recommended media weight (duplex)
Only simplex in this model
Recommended monthly page volume
250 to 2500
Recommended monthly page volume note
Recommends that the number of printed pages per month be within the stated range for optimum device performance, based on factors including supplies replacement intervals and device life over an extended warranty period.
Recommended operating humidity range
30 to 70% RH
Recommended operating temperature range
63.5 to 77°F
Replacement cartridges
158A Black LaserJet Tank Toner Reload Kit (Yield ~2500 pages); 158X Black LaserJet Tank Toner Reload Kit (Yield ~5000 pages);
Replacement cartridges footnote
Declared yields based on ISO/IEC 19752 and continuous printing. Actual yields vary considerably based on images printed and other factors.
Safety
IEC 60950-1:2005 +A1:2009+A2:2013; IEC/EN 62368-1:2014; CAN/CSA C22.2 No. 62368-1, 3rd Edition; UL62368-1, 3rd Edition; IEC 60825-1 3rd Edition (Class 1 Laser Product); EN 62479:2010 / IEC 62479:2010; Compliance of IEC 60950-1 standard considers all country deviations according to the most recent IECEE CB Bulletin; Complies with FDA performance standards for laser products except for conformance with IEC 60825-1 Ed.3.,as described in Laser Notice No. 56, dated May 8, 2019
Security management
Secure Boot, Secure Firmware Integrity, Runtime Code Integrity, password protected EWS, secure browsing via SSL/TLS 1.0, TLS 1.1, TLS 1.2; TLS 1.0/1.1 disabled by default; OpenSSL version 1.1.1; Enable/disable Network ports; SNMPv1, SNMPv2, and SNMPv3, Community password change; Secure defaults, Encrypted data at rest, Active FW update, Admin password by default, Cipher & TLS selection; Account lockout; Secure Wi-Fi setup
Software included
No CD inbox (except Indonesia and China Gov) Downloadable Software CD include Software Installer, Uninstaller, printer driver and other essential tools
Standard input capacity (envelopes)
Up to 10 envelope
Standard output capacity (envelopes)
Up tp 10
Storage temperature range
-4 to 140°F
Supplies feature
LaserJet Tank Technology
Sustainability specifications
Recyclable through Planet Partners; Contains post-consumer recycled plastic
Target user and print volume
For teams up to 5 users; Prints up to 2,500 pages/month
Tariff numbers
(AM) 8443321010; (EU) 8443321000; (AP) 84433239
Technical features
Auto-On/Auto-Off; Compact size; Professional print quality
Top key features
Compact Size; Energy Efficient
Typical electricity consumption (TEC) footnote
[2] Power requirements are based on the country/region where the printer is sold. Do not convert operating voltages. This will damage the printer and void the product warranty. Energy Star value typically based on measurement of 115V device.
Warm-up time
As fast as 20 sec
Weight note (imperial)
base on unit with Tray and cartridge installed
What is in the box footnote
Black Original LaserJet Tank Imaging Drum (introductory ~5,000 page black toner yield provided). For yield information included with your printer. Yield values measured in accordance with ISO/IEC 19752 and continuous printing. Actual yields vary considerably based on images printed and other factors.
What's in the box
Black Original LaserJet Tank Imaging Drum (~5000 page black toner yield provided), Power Cord, Setup Guide, Reference Guide, Regulatory/Support Flyers
